1. UPDATE YOUR FIRMWARE: Please upgrade the firmware on your Helix and the HX Edit software from Line 6 to the latest before installing this patch. Even if your Helix is up to date, the ‘HX Edit’ app needs to be updated as well.
2. REVERBS: The 2.6 Firmware update changed the mix levels of the new (HX) reverbs. This patch accounts for those changes, so if you are not updated to 2.6 or later on your Helix, the reverbs will not sound right.
3. IR CABS: This download contains both stock and IR cab versions. We think they both sound great, but if you’d like to use the specific IR we used, it’s from the ATyp 2×12 IR Set from Live Ready Sound (available here). Here is the specific IR:
- LRS M2 SM7b PR20 ATyp Mix (slot 40 in our Helix)
This patch is designed to be used in Snapshot mode. To enable this mode in your Helix, go to the ‘Footswitches’ section of the Global Settings and select ‘8 Snapshots’ in the ‘Preset Mode Switches’ menu. Here are the snapshots:
- SNAPSHOT 1: INTRO/RIFF. Big ambient lead tone.
- SNAPSHOT 2: CH1/SWELLS. Ambient swells for CH1 (or anything you want swells for)
- SNAPSHOT 3: VS2. Clean tone with chorus
- SNAPSHOT 4: CH BIG. Main rhythm drive tone
- SNAPSHOT 5: BRIDGE/CLN: Clean tone with chorus
- SNAPSHOT 6: Not used.
- SNAPSHOT 7: Not used.
- SNAPSHOT 8: SWELLS. I guess we put swells in here twice 🙂
SIGNAL FLOW AND EFFECTS
Here is the signal flow and effects:
- Volume (log curve) – mapped to EXP 2
- Kinky Comp – not mapped to a switch, always on
- PlastiChorus – not mapped to a switch
- Minotaur – Klon OD – mapped to switch labeled ‘Klon’
- Compulsive Drive – OCD Distortion – mapped to switch labeled ‘OCD’
- Scream 808 – Tube Screamer OD – mapped to switch labeled ‘808’
- Amps: AC Fawn Nrm, Brit J45 Brt
- Vintage Digital – Dotted 8th note delay – mapped to switch labeled ‘1/8d DLY’
- Transistor Tape Delay – Quarter note delay – mapped to switch labeled ‘1/4 DLY’
- Hall verb – ‘always on’ type reverb – mapped to switch labeled ‘Hall’
- Glitz Verb – big modulated verb – mapped to switch labeled “Big Verb (Mod)”
- Multitap 4 Delay – Big ambient delay – mapped to switch labeled ‘Ambient/Swells’
- Glitz Verb – mapped to switch labeled ‘Swells’
- Cali Q Graphic – always on EQ – not mapped to a switch
- Looper (6 button) – mapped to switch labeled ‘Looper’
This patch is meant to be used snapshot mode, but you can switch to stomp at any time to get to the individual effects. We recommend setting up your Helix to use all ten stomps. The Helix LT does not allow 10-button stomp mode, so you’ll have to re-arrange the button assignments to suite your preferences.
Everything after the cab block runs in stereo. The delays are mono, but they are panned using the mixer block. All the verbs and effects after the delays are stereo effects. If you are able to run stereo, the wet effects will sound bigger and better. If you only use the L/Mono output of the Helix, everything will be summed to mono automatically. NOTE: Do not use just the Right output of the helix – some of the delays will not be audible if you do this.
Feel free to stack drive pedals for bigger sounds. For a lead tone, we like the 808 into the OCD.
The dotted 8th delay is in parallel with the quarter delay, so they’ll be more rhythmic when used together.
Hit the ‘Swells’ button to turn on the Cosmos echo with big ambient reverb.
EQ AT THE END OF THE CHAIN?:
Typically when you record guitar parts in the studio, you’ll put EQ and compression on the final tone. We’ve replicated the EQ in this patch. You can use the Cali Q Graphic block for final tone shaping. See below for recommended settings.
MAKING ADJUSTMENTS FOR YOUR SETUP
SETTING THE PATCH UP FOR YOUR GUITAR
All guitars are different, so you may want to make changes to suite your playing style and guitar. We set this up with a variety of guitars, including both single coils and humbuckers (primarily a Telecaster style guitar). If you’re using a guitar with humbuckers, please refer to the suggested settings below.
We recommend making a copy of the patch and changing the copy just in case you want to revert back to the original.
RECOMMENDED SETTINGS FOR SINGLE COILS:
The version of this patch you initially download is voiced more toward single coils. We built it primarily using a Telecaster style guitar. If you have a humbucker equipped guitar with low-output humbuckers, it should be perfect for your uses too.
RECOMMENDED SETTINGS FOR HUMBUCKERS:
If your guitar has traditional output Humbuckers, try the following changes (we recommend making a copy of the original patch)…
- AC30 Fawn Gain: Change to 6.0
- AC30 Fawn Treble: Change to 8.4
- AC30 Fawn Presence: Change to 6.4
- J45 Treble: Change to 9.6
CALI Q GRAPHIC SETTINGS:
- 2200 Hz Slider: Change to 3.0
- 6600 Hz Slider: Change to 1.9
If you would like to make this patch louder or quieter without affecting tone, the following adjustments can be made:
“Ch Vol” control on the amp module. This will increase or decrease volume without affecting the tone of the amp. This is the primary level adjustment tool I use for changing patch volumes.
Output block level. Changing the level control on the output block (the very last thing in the signal chain) will increase or decrease overall volume. We typically have this set at zero, but feel free to adjust this as you see fit.
Initial Release: 2016-06-19
Version 2.0 Release: 2018-12-01
- Changed: New amp(s) section for much improved tone
- Changed: All new reverbs
Tweaked: Delays settings
- Tweaked: Drive section (way better drive tones)
- Added: Everything after the amps runs in stereo
- Added: End of chain EQ (improved clarity)
- Added: Suggested settings for single coils and humbuckers
