In this demo Bradford is using a Shelton Electric Instruments SkyFlite IV. NOTE: This demo was made with version 1.0 of this patch. We’ve made significant upgrades – scroll down to see how we’ve improved it.
1. UPDATE YOUR FIRMWARE: Please upgrade the firmware on your Helix and the HX Edit software from Line 6 to the latest before installing this patch. Even if your Helix is up to date, the ‘HX Edit’ app needs to be updated as well. If you get an error importing a patch, the problem is most likely outdated firmware on your Helix/HX Edit. You will need at least firmware 2.8.
2. REVERBS: The 2.6 Firmware update changed the mix levels of the new (HX) reverbs. This patch accounts for those changes, so if you are not updated to 2.6 or later on your Helix, the reverbs will not sound right.
3. IR CAB INCLUDED: This download includes a premium IR from Tone Junkie. We matched this specific IR to this amp, but feel free to experiment with other IR’s for different tonal options. We’ve also included a stock cab version of the patch, but we urge to try the IR – it really does sound better – and it’s included for free :).
Here is the specific IR included, and its location in our Helix:
- TJ 21 MATCH 25 R121+57 (top row) . In our Helix, it’s in IR slot 21 (this will always correspond with the number after ‘TJ’ in the file name).
To purchase more IR packs, visit the Tone Junkie store here.
This patch is designed to be used in Snapshot mode. To enable this mode in your Helix, go to the ‘Footswitches’ section of the Global Settings and select ‘8 Snapshots’ in the ‘Preset Mode Switches’ menu. Here are the snapshots:
- SNAPSHOT 1: INTRO/RIFF. The main lead line of the song. Technically it’s a synth in the recording, but feel free to go wild.
- SNAPSHOT 2: VERSE 1. Clean-ish tone for the first verse.
- SNAPSHOT 3: CHORUS. Main rhythm drive tone.
- SNAPSHOT 4: VERSE 2. Lots of modulation and delay.
- SNAPSHOT 5: BRIDGE: Clean tone with reverse delay
- SNAPSHOT 6: VERSE VIB. This is the vibrato part in the first verse – we positioned it directly above the Verse 2 snapshot so it’s easy to go back and forth.
- SNAPSHOT 7: CLEAN AMBI: This song doesn’t really have any ambient clean parts, but this is a good sound to have at your feet if the moment calls for it.
- SNAPSHOT 8: SWELLS: Just like the clean ambi snap, there aren’t swells in this song, but it’s a great sound to be able to switch to.
SIGNAL FLOW AND EFFECTS
Here is the signal flow and effects:
- Volume (log curve) – mapped to EXP 2
- Deluxe Comp – not mapped to a switch, always on
- Bubble Vibrato – mapped to a switch labeled ‘Bubble Vibrato’
- Dual Pitch – mapped to a switch labeled ‘Dual Pitch’
- Heir Apparent – Prince of Tone (voiced to sound like Bradford’s KOT, Yellow side) – mapped to switch labeled ‘KOT-Yellow’
- Scream 808 – Tube Screamer OD – mapped to switch labeled ‘808’
- Dhyna Drive – Hermida Zen Drive – mapped to switch labeled ‘Zen’
- Amp – Matchstick Jump
- Dual Pitch – not mapped to a switch
- Cab/IR – see above for IR info
- Vintage Digital – Dotted 8th note delay – mapped to switch labeled ‘1/8d DLY’
- Reverse Delay – not mapped to a switch
- Vintage Digital – 8TH note delay – mapped to switch labeled ‘1/8 DLY’
- Plate verb – subtle ‘always on’ type reverb – mapped to switch labeled “Big Verb’
- Glitz Verb – big modulated verb – mapped to switch labeled “Long Verb”
- Multitap 4 Delay – big ambient delay mapped to button labeled “SWELLS’
- Glitz Verb – big ambient verb – mapped to button labeled ‘SWELLS’
- Simple EQ – Always on EQ – Use this EQ to make tonal tweaks for your guitar/setup. These controls will affect your tone differently than the amp controls. See below for recommended settings.
This patch is meant to be used in snapshot mode, but can be used in stomp box mode. We recommend setting up your Helix to use all ten stomps (stompbox mode) or all eight snapshots (snapshot mode). The Helix LT does not allow 10-button stomp mode, so you’ll have to re-arrange the button assignments to suite your preferences.
Everything after the cab block runs in stereo. The delays are mono, but they are panned using the mixer block. All the verbs and effects after the delays are stereo effects. If you are able to run stereo, the wet effects will sound bigger and better. If you only use the L/Mono output of the Helix, everything will be summed to mono automatically. NOTE: Do not use just the Right output of the helix – some of the delays will not be audible if you do this.
Feel free to stack drive pedals for bigger sounds. All three one at once will give you a lead/solo tone.
The dotted 8th delay is in parallel with both the quarter and eight delays, so they’ll be more rhythmic when used together. They are also set to output in stereo when the Helix is used in stereo (using both outputs). If you only use the Left/Mono output, the entire patch will be summed to Mono.
Hit the ‘Swells’ button to turn on the Cosmos echo with big ambient reverb and shimmer.
EQ AT THE END OF THE CHAIN?:
Typically when you record guitar parts in the studio, you’ll put EQ and compression on the final tone. We’ve replicated the EQ in this patch. You can use the Cali Q Graphic block for final tone shaping. See below for recommended settings.
MAKING ADJUSTMENTS FOR YOUR SETUP
SETTING THE PATCH UP FOR YOUR GUITAR
All guitars are different, so you may want to make changes to suite your playing style and guitar. We set this up with a variety of guitars, including both single coils and humbuckers (primarily a Telecaster style guitar). If you have higher output humbuckers, you might want to make adjustments based on the suggestions below.
We recommend making a copy of the patch and changing the copy just in case you want to revert back to the original.
RECOMMENDED SETTINGS FOR SINGLE COILS:
The version of this patch you initially download is voiced more toward single coils. We built it primarily using a Telecaster style guitar. If you have a humbucker equipped guitar with low-output humbuckers, it should be perfect for your uses too.
Feel free to adjust the amp EQ and the settings of the Cali Q Graphic block (at the end of the patch) if you’d like to make the patch a bit brighter or darker.
RECOMMENDED SETTINGS FOR HUMBUCKERS:
If your guitar has traditional output Humbuckers, try the following changes (we recommend making a copy of the original patch)…
- CH 1Drive: Change to 0.9
- Bass: Change to 2.5
- Cut: Change to 3.0
If you would like to make this patch louder or quieter without affecting tone, the following adjustments can be made:
“Ch Vol” control on the amp module. This will increase or decrease volume without affecting the tone of the amp. This is the primary level adjustment tool I use for changing patch volumes.
Output block level. Changing the level control on the output block (the very last thing in the signal chain) will increase or decrease overall volume. We typically have this set at zero, but feel free to adjust this as you see fit.
Version 3.0: 2019-08-13 (TONE JUNKIE IR UPDATE)
- Changed: IR cab – includes a premium Tone Junkie IR Cab for free 🙂
- Changed: Amp model (we switched to the Matchless Jumped amp model)
- Changed: Drive models (we switched to the King of Tone and Zendrive models)
- Changed: End of chain EQ (to better suit the new amp model)
Version 2.0: 2019-02-27
This is a complete overhaul of this patch
- Added: New HX Reverbs from firmware 2.5
- Added: End of chain EQ
- Added: Suggested settings for single coils and humbuckers (via the ReadMe file)
- Improved: Amp settings – better tone
- Improved: Drive block settings
- Improved: Swells blocks settings
- Changed: Output level has been adjusted – we suggest running your Helix with the big volume knob at 100% (unity gain)
- Changed: IR cab suggestion – using an IR from the same IR pack as the rest of our updated patches
Version 1.0 (Initial Release): 2017-12-01
